Description
THIS LED CORN LIGHT IS APPLIED TO WIDELY USED IN MAIN STEM, HIGHWAY, ELEVATED ROAD, STREET, OVERLINE BRIDGE AND SQUARE, SCHOOL, DWELLING DISTRICT, INDUSTRIAL AREA, PARK.
Packing:
|
Part Item |
Power |
Voltage |
Efficiency |
CCT |
Equal to |
|
AIS-OC7-102 |
27W |
AC90-265/277V |
120lm/W |
2700-6500K |
75W HID HME etc |
|
AIS-OC7-102 |
36W |
AC90-265/277V |
120lm/W |
2700-6500K |
125W HID HME etc |
|
AIS-OC7-102 |
45W |
AC90-265/277V |
120lm/W |
2700-6500K |
175W HID HME etc |
|
AIS-OC7-102 |
54W |
AC90-265/277V |
120lm/W |
2700-6500K |
200W HID HME etc |
|
Part Item |
Power |
Voltage |
Efficiency |
CCT |
Equal to |
|
AIS-OC7-102 |
80W |
AC90-265/277V |
120lm/W |
2700-6500K |
250W HID HME etc |
|
AIS-OC7-102 |
100W |
AC90-265/277V |
120lm/W |
2700-6500K |
300W HID HME etc |
|
AIS-OC7-102 |
120W |
AC90-265/277V |
120lm/W |
2700-6500K |
400W HID HME etc |
Packing:
|
Watt |
27W |
36W |
45W |
54W |
|
Product Size |
E27：Φ*H=93*204 mm E40：Φ*H=93*209 mm |
E27：Φ*H=93*234 mm E40：Φ*H=93*239 mm |
E27：Φ*H=93*265 mm E40：Φ*H=93*270 mm |
E27：Φ*H=93*275 mm E40：Φ*H=93*280 mm |
|
Package Size(mm) |
110*110*230 mm |
110*110*260 mm |
110*110*290 mm |
110*110*300 mm |
|
Net（kg）/Pcs |
0.65 kg |
0.76 kg |
0.81 kg |
0.93 kg |
|
Gross（kg）/Pcs |
0.72 kg |
0.84 kg |
0.92 kg |
1.01 kg |
|
Pick Up Qty |
12 pcs |
12 pcs |
12 pcs |
12 pcs |
|
Carton Size（mm） |
450*245*340 mm |
450*275*340 mm |
450*305*340 mm |
450*315*340 mm |
|
Net（kg）/Cot |
7.8 kg |
9.12 kg |
9.72 kg |
11.16 kg |
|
Gross（kg）/Cot |
9.28 kg |
11.3 kg |
11.7 kg |
12.84 kg |
|
CBM（m³） |
0.038 m³ |
0.042 m³ |
0.047 m³ |
0.048 m³ |
|
Watt |
80W |
100W |
120W |
|
Product Size |
E40：Φ*H=118*312 mm |
E40：Φ*H=118*342 mm |
E40：Φ*H=118*377 mm |
|
Package Size(mm) |
130*130*315 mm |
130*130*355 mm |
130*130*390 mm |
|
Net（kg）/Pcs |
1.838 kg |
2.04 kg |
2.24 kg |
|
Gross（kg）/Pcs |
1.92 kg |
2.15 kg |
2.36 kg |
|
Pick Up Qty |
6 pcs |
6 pcs |
6 pcs |
|
Carton Size（mm） |
400*325*270 mm |
400*370*270 mm |
400*405*270 mm |
|
Net（kg）/Cot |
11.03 kg |
12.24 kg |
13.44 kg |
|
Gross（kg）/Cot |
12.17 kg |
13.55 kg |
14.81 kg |
|
CBM（m³） |
0.035 m³ |
0.04 m³ |
0.044 m³ |
Installation:
